| quantitas; | |
|---|---|
Xlpe compositis de Monosil modum ad aeria filum et funem usque ad 10kv
Haec materia est quaedam calida aqua crosslinkable polyethylene tincidunt compositis. Est processionaliter per altum qualitas polyethylene resinae, silanene copulatis agente, initiator, antioxidant agente, catalyst et aliis additives. Hoc est optimum extrusionem perficientur, stabilis corporis et eget index; Velox extrudens celeritate et lenis superficies.
Application: 10kv et sub aeria funem velit; Maximum opus temperatus est 90c.
Res
Item | Unitas | Vexillum vana | |||
Tensile vires | MPA | IEC 60811- 1. I | ≥ 13.5 | 18.5 | |
Elongatio ad confractus | % | ≥ CCCL | 465 | ||
Impact Embrittlement perficientur @ -76c | Defectum Number | Pars | ASTM D746 | ≤15 / XXX | 0/30 |
Post senescentis @ 135c, 168h | Tensile vires variation | % | IEC 60811- 1-2 | ± XX | VII |
Effrego elongatio variation | % | ± XX | I | ||
Hot prolongation @ CC c , 0 .2 MPa , 15min | Elongatio sub onus | % | IEC 60811-2- I | ≤80 | 50 |
% | ≤5 | 0 | |||
Dielectric dissipatio factor @ 20c, 50Hz | － | IEC (LX) CCL | ≤0.001 | 0.0003 | |
Dielectric Constans @ 20C 50Hz | － | ≤ 2.35 | 2.25 | ||
Dielectric Fortitudo @ 20C | MV / M | IEC 60243- I | ≥ XXV | 37 | |
Ω · m | IEC (LX) XCIII | ≥ V × MXIII | VI × MXIV | ||
Environmental accentus crack resistentiam F50 | hr | IEC 811-4-1 | ≥ M | Transeo | |
Artificialis Clima senescit resistentia (After42 dies) | Tensile vires variation | % | GB / T (XIV) XLIX | ± XXX | - XIX |
Effrego elongatio variation | % | ± XXX | -25 | ||
Artificialis caeli senescit resistentia (post XXI diebus) | Tensile vires variation | % | ± XV | -9 | |
Effrego elongatio variation | % | ± XV | - XI | ||
Processu
Suadeo enim Polyethylene specifica extruder. Ducat Ratio est a XVIII: I ad XXV: I et alia apparatu opus ad esse adaequatum secundum circumstantiam.
Zona | Feodo Ding sectioni | Section compressionem | Homogenization sectioni | Section |
Temperature range C | CLXXX 160- | 180-200 | 200-220 | 220-230 |
- supra temperatus est tantum pro reference.
Reference Cross-Coniuratione
Nam generalis funem Stuulationem layer (I mm in crassitudine) potest esse crucem, coniunctum postquam lotus in 90c supra calida aqua ad IV horas. Si crassitiem vel maior sit oportet extendere balneum tempore. Extended a 1mm / 4h vel extend tempus secundum speciem calor extenditur notitia.
Repono
Custodi locus temperatus; Repono environment mundare arida et uentilandam; usum Optimus intra sex menses a date productio ; placet utitur in horas 16 post peram aperitur .
Product sarcina
25Kg in humorem repugnans aluminium laminated sacculos cum composita charta sacculos foras; Palletized deorsum.
Xlpe compositis de Monosil modum ad aeria filum et funem usque ad 10kv
Haec materia est quaedam calida aqua crosslinkable polyethylene tincidunt compositis. Est processionaliter per altum qualitas polyethylene resinae, silanene copulatis agente, initiator, antioxidant agente, catalyst et aliis additives. Hoc est optimum extrusionem perficientur, stabilis corporis et eget index; Velox extrudens celeritate et lenis superficies.
Application: 10kv et sub aeria funem velit; Maximum opus temperatus est 90c.
Res
Item | Unitas | Vexillum vana | |||
Tensile vires | MPA | IEC 60811- 1. I | ≥ 13.5 | 18.5 | |
Elongatio ad confractus | % | ≥ CCCL | 465 | ||
Impact Embrittlement perficientur @ -76c | Defectum Number | Pars | ASTM D746 | ≤15 / XXX | 0/30 |
Post senescentis @ 135c, 168h | Tensile vires variation | % | IEC 60811- 1-2 | ± XX | VII |
Effrego elongatio variation | % | ± XX | I | ||
Hot prolongation @ CC c , 0 .2 MPa , 15min | Elongatio sub onus | % | IEC 60811-2- I | ≤80 | 50 |
% | ≤5 | 0 | |||
Dielectric dissipatio factor @ 20c, 50Hz | － | IEC (LX) CCL | ≤0.001 | 0.0003 | |
Dielectric Constans @ 20C 50Hz | － | ≤ 2.35 | 2.25 | ||
Dielectric Fortitudo @ 20C | MV / M | IEC 60243- I | ≥ XXV | 37 | |
Ω · m | IEC (LX) XCIII | ≥ V × MXIII | VI × MXIV | ||
Environmental accentus crack resistentiam F50 | hr | IEC 811-4-1 | ≥ M | Transeo | |
Artificialis Clima senescit resistentia (After42 dies) | Tensile vires variation | % | GB / T (XIV) XLIX | ± XXX | - XIX |
Effrego elongatio variation | % | ± XXX | -25 | ||
Artificialis caeli senescit resistentia (post XXI diebus) | Tensile vires variation | % | ± XV | -9 | |
Effrego elongatio variation | % | ± XV | - XI | ||
Processu
Suadeo enim Polyethylene specifica extruder. Ducat Ratio est a XVIII: I ad XXV: I et alia apparatu opus ad esse adaequatum secundum circumstantiam.
Zona | Feodo Ding sectioni | Section compressionem | Homogenization sectioni | Section |
Temperature range C | CLXXX 160- | 180-200 | 200-220 | 220-230 |
- supra temperatus est tantum pro reference.
Reference Cross-Coniuratione
Nam generalis funem Stuulationem layer (I mm in crassitudine) potest esse crucem, coniunctum postquam lotus in 90c supra calida aqua ad IV horas. Si crassitiem vel maior sit oportet extendere balneum tempore. Extended a 1mm / 4h vel extend tempus secundum speciem calor extenditur notitia.
Repono
Custodi locus temperatus; Repono environment mundare arida et uentilandam; usum Optimus intra sex menses a date productio ; placet utitur in horas 16 post peram aperitur .
Product sarcina
25Kg in humorem repugnans aluminium laminated sacculos cum composita charta sacculos foras; Palletized deorsum.
