Steel Wire Armored 0.6/1kV XLPE Power Cable Copper Conductor

5 0 Recensiones

Product Introductio: Steel filum armatae 0.6/1kV XLPE Power Cable cum Conductor aeris

Hoc Ferro Wire armatae 0.6/1kV XLPE Potestas Cable machinata est ad distributionem robustam et firmam potestatem in applicationibus industrialibus et infrastructuris exigendis. Lorem conductorem aeris conductoris et XLPE (Cross-Coniunctum Polyethylene) velit, praestantiorem electricam observantiam et scelerisque stabilitatem praestat usque ad 90°C. Clavis tutelae elementum, filum ferreum armaturae (SWA) - eximiam vim mechanicam praebet, funem contra contritionem, impulsum et rodentem damnum conservans, aptam facit ad sepulturam directam, sub terra institutionem, ac usum in ferculis vel ductus in plantis industrialibus, fodiendis operationibus et utilitatibus substationibus.

Medium voltage (MV) potentiae retiacula destinata, haec gravis officiorum funis cum signis internationalibus obtemperat ut IEC 60502-1 et BS 5467, salutem et durabilitatem in asperis ambitibus praestans. Constructio diuturnum firmitatem praestat potentiae transmissionis in retiacula subterranea, renovationem energiam inceptis (rura solar/venti), et fabricam situs potentiae commeatus.

quantitas;
Availability:





Inquire Addere ad cartallum

Product Description

Gravis-Officium 6kV Power Cable - Copper Conductor, XLPE Insulation, Ferro Wire Armored (SWA)

Generativus

Gravis Officium 6kV Potentiae Cable cum Conductore et XLPE Insulation, a Ferro Wire Armouring (SWA) munitum est valida et certa solutio ad tradendam electricam potestatem in ambitibus quaerendis.

Hic funis specifice machinatur ad applicationes mediae intentionis ubi vires mechanicae, effectus electricae et diuturnitas critica sunt.

Typical applications

Sector	Exempla
Industriae	Potentia distributio, fodienda, facultas petrochemical
Virtus networks	Sub retia, substatio feeders
Energy	Villae solares, venti potentiae officinae
Infrastructure	Cuniculi, nisl, railways

Clavis Construction

Material	beneficium
Conductor	Summus conductivity aeris	Optimum electrica perficientur
Initium	XLPE (polyethylene crucis coniunctum)	Stabilitas scelerisque, robur dielectric
Armor	Arma filum ferro (SWA)	Mechanica praesidio contra impulsum, compressionem, accentus distrahentes

Signa & certificaciones

IEC Signa

Standard	Description
IEC 60502-1	Virtus retinacula extrusa velit - I kv ad XXX kV
IEC 60228	Conductores e rudentibus insulatis
IEC 60332	Propagationem flammae verticalis probat
IEC 60754	Gas evolutionis in combustione (mordax / vapores toxicus)
IEC 60811	Test modi insulating / vaginatus materiae
IEC 61034	Fumus densitas mensurae

ISO Signa

Standard	Description
ISO 9001	Qualitas systemata procuratio

Signa Regional (Libitum)

Standard	Region
BS 5467/ BS 6622	Britannicus
DIN VDE 0276	German
GB/T 12706	Seres
IEEE 48	Terminationes pro AC cables

Testis & Documentation

Omnes probationes in laboratoriis adprobatis agebantur. Praesto tradit:

Typus test tradit
Exercitatione test tradit
Factory acceptatio test tradit

Quid hoc cable elige?

Pluma	beneficium
Conductor aeris	Princeps conductivity, perficientur certa
XLPE velit	Stabilitas scelerisque, vitae tempor
Filum ferro armis	Mechanica tutela dura ambitibus
IEC obsequentem	International acceptatio
ISO 9001 certified	Qualitas consistent, traceability

Technical Paramater

3,6 / VI (7.2) KV, xlpe insulated unarmored PVC pessima potentia funem

Single-Core, Cu / xlpe / PVC aut al / XLIV / PVC (Table XIX)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	kg / km		m
10	2.5	1.8	15	320	260	500
16	2.5	1.8	18	390	290	500
25	2.5	1.8	20	500	340	500
35	2.5	1.8	21	610	400	500
50	2.5	1.8	22	750	450	500
70	2.5	1.8	24	970	550	500
95	2.5	1.8	25	1,250	660	500
120	2.5	1.8	27	1,500	760	500
150	2.5	1.8	28	1,790	860	500
185	2.5	1.9	30	2,150	1,000	500
240	2.6	1.9	33	2,770	1,250	500
300	2.8	2.0	35	3,400	1,500	500
400	3.0	2.1	39	4,280	1.850	500
500	3.2	2.2	43	5,400	2,280	500
630	3.2	2.4	47	6.830	2,800	500
800	3.2	2.5	51	8.570	3,400	400
1,000	3.2	2.6	56	10,590	4,110	300

Tres-Core, Cu / xlpe / PVC et al / XLX / PVC (Tabula XX)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	kg / km		m
10	2.5	1.9	33	980	790	500
16	2.5	2.0	35	1,190	890	500
25	2.5	2.1	38	1,560	1,080	500
35	2.5	2.2	40	1,930	1,270	500
50	2.5	2.3	43	2,370	1,480	500
70	2.5	2.4	47	3,110	1,820	500
95	2.5	2.5	51	4,000	2,200	500
120	2.5	2.6	54	4,820	2,550	500
150	2.5	2.7	58	5,770	2,970	500
185	2.5	2.8	61	6,960	3,460	500
240	2.6	3.0	68	8.940	4,340	400
300	2.8	3.2	73	10,980	5.190	300
400	3.0	3.5	81	13.820	6.440	250
500	3.2	3.7	90	17,390	7.910	200

3,6 / VI (7.2) KV, xlpe insulated filum armis PVC pusillae potestatem funem

Single-Core, Cu / xlpe / Awa / PVC Oral / xlpe / Awa / PVC (Table XXI)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	0.9	1.8	22	610	550	500
16	2.5	1.2	1.6	1.8	24	680	580	500
25	2.5	1.2	1.6	1.8	25	810	660	500
35	2.5	1.2	1.6	1.8	26	940	730	500
50	2.5	1.2	1.6	1.8	27	1,100	810	500
70	2.5	1.2	1.6	1.8	29	1,350	930	500
95	2.5	1.2	1.6	1.9	31	1,670	1,080	500
120	2.5	1.2	1.6	1.9	32	1,950	1,200	500
150	2.5	1.2	1.6	2.0	34	2,270	1,350	500
185	2.5	1.2	2.0	2.1	37	2,770	1,620	500
240	2.6	1.2	2.0	2.2	40	3,440	1,930	500
300	2.8	1.2	2.0	2.2	42	4,120	2,210	500
400	3.0	1.3	2.5	2.4	47	5,250	2,820	500
500	3.2	1.3	2.5	2.5	51	6,450	3,340	500
630	3.2	1.4	2.5	2.6	55	7,990	3,950	400

Tres-Core, Cu / xlpe / SWA / PVC et al / xlpe / SWA / PVC (Table XXII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	2.0	2.1	40	2,310	2,120	500
16	2.5	1.2	2.0	2.2	42	2,600	2,290	500
25	2.5	1.2	2.0	2.3	45	3,080	2,600	500
35	2.5	1.3	2.5	2.4	48	3,950	3,280	500
50	2.5	1.3	2.5	2.5	54	4,530	3,630	500
70	2.5	1.4	2.5	2.6	55	5,510	4,210	500
95	2.5	1.5	2.5	2.8	59	6,660	4,860	500
120	2.5	1.5	2.5	2.9	63	7,630	5,360	400
150	2.5	1.6	2.5	3.0	66	8,800	6,000	400
185	2.5	1.7	3.15	3.2	72	11,500	6.670	300
240	2.6	1.8	3.15	3.4	78	13,480	8.870	250
300	2.8	1.9	3.15	3.6	84	15,920	10,130	200
400	3.0	2.0	4.0	3.9	94	21,300	12,590	200
500	3.2	2.1	4.0	4.1	103	25.090	15,610	200

3,6 / VI (7.2) KV, xlpe insulatas tape armis PVC pusillae potestatem funem

Single-Core, Cu / xlpe / ATA / Pvcor Al / xlpe / Ata / PVC (Table XXIII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Arma Filum Magnitudo	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Arma Filum Magnitudo	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	0.5	1.8	22	530	460	500
16	2.5	1.2	0.5	1.8	23	600	500	500
25	2.5	1.2	0.5	1.8	24	730	570	500
35	2.5	1.2	0.5	1.8	25	850	630	500
50	2.5	1.2	0.5	1.8	26	1,000	700	500
70	2.5	1.2	0.5	1.8	28	1,240	820	500
95	2.5	1.2	0.5	1.8	30	1,540	950	500
120	2.5	1.2	0.5	1.8	31	1,820	1,080	500
150	2.5	1.2	0.5	1.9	33	2,120	1,200	500
185	2.5	1.2	0.5	1.9	35	2.520	1,370	500
240	2.6	1.2	0.5	2.0	37	3,180	1,670	500
300	2.8	1.2	0.5	2.1	40	3,850	1,950	500
400	3.0	1.3	0.5	2.3	44	4,800	2,370	500
500	3.2	1.3	0.5	2.4	48	5,960	2,840	500
630	3.2	1.4	0.5	2.5	52	7,450	3,410	600

Tres-core, cu / xlpe / sta / pvcor al / xlpe / sta / pvc (mensam XXIV)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	0.2	2.0	37	1,330	1,140	500
16	2.5	1.2	0.5	2.1	40	1,580	1,580	500
25	2.5	1.2	0.5	2.2	42	2,310	1,880	500
35	2.5	1.3	0.5	2.3	45	2,760	2,090	500
50	2.5	1.3	0.5	2.4	48	3,260	2,360	500
70	2.5	1.4	0.5	2.5	52	4,100	2,810	500
95	2.5	1.5	0.5	2.7	56	5.10	3,310	500
120	2.5	1.5	0.5	2.8	60	5,010	3,750	400
150	2.5	1.6	0.5	2.9	63	7,050	4,250	400
185	2.5	1.7	0.5	3.0	67	9.320	4,820	400
240	2.6	1.8	0.5	3.2	73	10,530	5,920	300
300	2.8	1.9	0.5	3.4	79	12,730	6.940	300
400	3.0	2.0	0.8	3.7	89	16.620	9.240	200
500	3.2	2.1	0.8	4.0	98	20,550	11,070	200

Features

Aeris conductor:

High conductivity ad efficient potestatem tradenda.
Optimum mechanica vires et diuturnitatem.
Idoneam ad grave-officium applications.

Xlpe (Cross-coniunctum polyethylene):

Providet optimum scelerisque et electrica proprietatibus.
High ad calorem, chemicals et humorem.
Operates efficiently ad altius temperaturis comparari PVC velit.

Steel Wire Armouring:

Offert superior mechanica tutela contra extrema, ut impulsum, adtritis et abrasione.
Enhances in funem in diuturnitatem in dura environments, possidet sub terra et industrialis occasus.

Voltage Rating:

Disposito medium-voltage applications usque ad 6kv.

Gravis-officium constructione:

Aedificavit resistere extrema condiciones faciens idealis industriae, metalla et velit installations.

Obsequio:

IEC occurrit internationalis signa ut IEC, BS, aut ASTM, cursus salus et reliability.

Applications

Industrial plantis: idoneam ad potentia distribution in officinis, refineries et eget plantis.
Mining Operations: Specimen pro aspera environments cum alta mechanica accentus.
Sub Installations: Tutus contra humorem et damnum.
Renewable Energy Projects: usus est in vento agris et solaris potentia plantis ad certum potentia tradenda.
Infrastructure projects: idoneam ad imperium grids, cuniculis et constructione sites.

applicatio

Commoda

High diuturnitatem: Steel filum armareing ensures diu term perficientur in lenta conditionibus.
Efficiente potentia tradenda: aeris conductor et xlpe Nulla minimize industria damna.
Safety: XLIPHIPRIPULUS praebet optimum resistentiam ad brevi circuitus et electrica vitia.
Fixe potest esse in fixa installationibus aut ubi mechanica accentus est spectat.

Technical specificationem

Voltage Rating: 6kv ((VI) Volts)
Conductor Material: aeris (Class II Stranded)
Vallum Material: xlpe (Cross-coniunctum polyethylene)
Armouring: Steel Wire Armor (SWA)
Sweath: PVC et Lszh (humilis fumus nulla halogen) pro additional praesidium
Temperature range: -20 ° C ad + XC ° C (operating)
Signa: IEC (LX) DII, BS (V) CDLXVII, aut equivalent

Stipare et shipping

Latin packaging: lignea agitator aut orbes (100m-5000m longitudines).

- Tutela: humorem-probationem involuti, inpulsa-absorbent grabatis.

- Labeling: patet voltage ratings, certificaciones et batch codes.

- Shipping obsequium: IEC (LX) CCXXVIII enim mechanica praesidii per transit.
