| quantitas; | |
|---|---|
Silanene xlpe compositis de Sioplas modum ad aeria filum et funem usque ad 10kv
Hoc materia est quaedam calida aqua crosslinkable polyethylene tecta compositis compositis et compositis B. compositis a summo qualis polyethylene resinae, ut ex Organotin Catalysts et Antioxidant agente. Damnum-in-pondus PASTOR quod praestat firmum praecisione components. Hoc est optimum extrusionem perficientur et stabilis corporis et eget index.
Application: 10kv et sub aeria funem velit; Maximum opus temperatus est XC ℃.
Res
Item | Unitas | Test modus | Vexillum vana | Typicus valor | |
Tensile vires | MPA | IEC 60811- 1. I | ≥ 13.5 | 18.5 | |
Elongatio ad confractus | % | ≥350 | 465 | ||
Impact Embrisstlement perficientur @ -76 ℃ | Defectum Number | Pars | ASTM D746 | ≤ 15/30 | 0/30 |
Post senescentis @ CXXXV ℃ , 168h | Tensile vires variation | % | IEC 60811- 1-2 | ± XX | VII |
Effrego elongatio variation | % | ± XX | + I | ||
Calidum prolongationem @ CC ℃ , 0.2MPA, 15min | Elongatio sub onus | % | IEC 60811-2- I | ≤80 | 50 |
Permanent deformatio | % | ≤5 | 0 | ||
Dielectric dissipatio factor @ XX ℃ , 50Hz | － | IEC (LX) CCL | ≤0.001 | 0.0003 | |
Dielectric Constans @ XX ℃ , 50Hz | － | ≤ 2.35 | 2.25 | ||
Dielectric Fortitudo @ XX ℃ | MV / M | IEC 60243- I | ≥25 | 37 | |
Volubilis resistivity @ XX ℃ | Ω · m | IEC (LX) XCIII | ≥ V × X13 | VI × X14 | |
Environmental accentus crack resistentiam f50 | r | IEC 811-4-1 | ≥ M | Transeo | |
Artificialis Clima senescit resistentia (After42 dies) | Tensile vires variation | % | GB / T (XIV) XLIX | ± XXX | - XIX |
Effrego elongatio variation | % | ± XXX | -25 | ||
Artificialis caeli senescit resistentia (post XXI dies) | Tensile vires variation | % | ± XV | -9 | |
Effrego elongatio variation | % | ± XV | - XI | ||
Processu
Suadeo enim Polyethylene specifica extruder. Ducat Ratio est a XVIII: I ad XXV: I et alia apparatu opus ad esse adaequatum secundum circumstantiam.
Zona | Pascens | Section compressionem | Homogenization sectioni | Section |
Temperatus range ℃ | CLXXX 160- | 180- CXC | 190-200 | 195-205 |
- supra temperatus est tantum pro reference.
Repono
Custodi locus temperatus; Repono environment mundare arida et uentilandam; Optimus usum intra sex menses a date ex productio; Mix compositis et B, quaeso uti in VIII horas; Composita debet esse in XXIV horas post aperuit.
Product sarcina
- 25kg in singulis sarcina, de quibus insertus polyethylene (compositis) est 23.75 kg / pera, catalytic magister Batch Material (compositis b) is 1.25 kg / peram.
- compositis A et B in humorem repugnans aluminium laminated sacculos cum composita charta sacculos foras.
Silanene xlpe compositis de Sioplas modum ad aeria filum et funem usque ad 10kv
Hoc materia est quaedam calida aqua crosslinkable polyethylene tecta compositis compositis et compositis B. compositis a summo qualis polyethylene resinae, ut ex Organotin Catalysts et Antioxidant agente. Damnum-in-pondus PASTOR quod praestat firmum praecisione components. Hoc est optimum extrusionem perficientur et stabilis corporis et eget index.
Application: 10kv et sub aeria funem velit; Maximum opus temperatus est XC ℃.
Res
Item | Unitas | Test modus | Vexillum vana | Typicus valor | |
Tensile vires | MPA | IEC 60811- 1. I | ≥ 13.5 | 18.5 | |
Elongatio ad confractus | % | ≥350 | 465 | ||
Impact Embrisstlement perficientur @ -76 ℃ | Defectum Number | Pars | ASTM D746 | ≤ 15/30 | 0/30 |
Post senescentis @ CXXXV ℃ , 168h | Tensile vires variation | % | IEC 60811- 1-2 | ± XX | VII |
Effrego elongatio variation | % | ± XX | + I | ||
Calidum prolongationem @ CC ℃ , 0.2MPA, 15min | Elongatio sub onus | % | IEC 60811-2- I | ≤80 | 50 |
Permanent deformatio | % | ≤5 | 0 | ||
Dielectric dissipatio factor @ XX ℃ , 50Hz | － | IEC (LX) CCL | ≤0.001 | 0.0003 | |
Dielectric Constans @ XX ℃ , 50Hz | － | ≤ 2.35 | 2.25 | ||
Dielectric Fortitudo @ XX ℃ | MV / M | IEC 60243- I | ≥25 | 37 | |
Volubilis resistivity @ XX ℃ | Ω · m | IEC (LX) XCIII | ≥ V × X13 | VI × X14 | |
Environmental accentus crack resistentiam f50 | r | IEC 811-4-1 | ≥ M | Transeo | |
Artificialis Clima senescit resistentia (After42 dies) | Tensile vires variation | % | GB / T (XIV) XLIX | ± XXX | - XIX |
Effrego elongatio variation | % | ± XXX | -25 | ||
Artificialis caeli senescit resistentia (post XXI dies) | Tensile vires variation | % | ± XV | -9 | |
Effrego elongatio variation | % | ± XV | - XI | ||
Processu
Suadeo enim Polyethylene specifica extruder. Ducat Ratio est a XVIII: I ad XXV: I et alia apparatu opus ad esse adaequatum secundum circumstantiam.
Zona | Pascens | Section compressionem | Homogenization sectioni | Section |
Temperatus range ℃ | CLXXX 160- | 180- CXC | 190-200 | 195-205 |
- supra temperatus est tantum pro reference.
Repono
Custodi locus temperatus; Repono environment mundare arida et uentilandam; Optimus usum intra sex menses a date ex productio; Mix compositis et B, quaeso uti in VIII horas; Composita debet esse in XXIV horas post aperuit.
Product sarcina
- 25kg in singulis sarcina, de quibus insertus polyethylene (compositis) est 23.75 kg / pera, catalytic magister Batch Material (compositis b) is 1.25 kg / peram.
- compositis A et B in humorem repugnans aluminium laminated sacculos cum composita charta sacculos foras.
