Provectus medium voltage xlpeta insulatas potestatem funem cum PVC vagina pro 3.6-6kv et 26-35kv ratings

5 0 Recensiones

Hoc medium voltage XLPE potentia insulata funem cum vagina PVC ordinatur ad certam distributionem in 3.6/6kV ad systemata 26/35kV. Utitur conductore cupro vel aluminio, velit XLPE, et PVC vagina exteriori. Funem aptum est ad officinas umbraticas, ductus ductus, fossas, et nexus commutandi ubi praesidium mechanicum non requiritur. Princeps continui conductor temperatus, humilis dielectricae detrimentum praebet, ac stabilis electricae effectus. Pro emptoribus, clavis pretii est integra intentione in una remulco familia, temporibus plumbi praevisis, et conductor magnitudinum, figurarum nucleorum, et colorum vaginarum ut specifationes inserere.

quantitas;
Availability:





Inquire Addere ad cartallum

Product Description

1. intentione Rating (U₀ / U)

Funem eligite secundum methodum intentionis et systematis fundationis. U₀ est aestimata potentia-frequency voltatio inter conductorem et velum; U est aestimatio intentionis inter conductores. Maxima ratio voltage Um non debet valorem certum dilabi non excedere.

Systema Nominale Voltage	Cable Rated intentione U/U	Maximum System Voltage Um
6 kV	3.6/6 kV	7.2 kV
10 kV	6/10 kV	12 kV
15 kV	8.7/15 kV	17.5 kV
20 kV	12/20 kV	24 kV
30 kV	18/30 kV	XXXVI KV
XXXV KV	26/35 kV	42 kV

Ad systemata non fundata seu sonora-fundata, altiorem U₀ rating desumo. Ad systemata efficaciter fundata, vexillum U/U rating plerumque sufficit.

2. Conductor Material and Cross-Section

Aeris: conductivity superior, brevis circuitu melioris effectus, ad circulos criticos et spatium institutionis limitatum accommodatus.
Aluminium: Pondus et impensa inferior, ad itinera longa apta ubi pondus et praevisiones sunt.
Crux-sectionis: Determinare per onus currentis, breve currentis circuii, gutta intentionis, temperatura ambientis, resistivity soli scelerisque, et factoris aggregationis. Medium voltage range: 25–630 mm².

3. Numerus Cores

Unius cori: Adhibentur in tribus systematibus systematis phase cum singulis funibus per tempus, saepe in ductus vel ferculis.
Trium cori: Usus ad distributionem directam et officinas fixas ubi unus funis omnes tres gradus portat. Communia pro 3.6/6kV ad 26/35kV.
Multi-core: Available ad certas potestates vel applicationes auxiliares.

4. Insulation

XLPE velit continuum conductorem temperatura XC°C et brevis circuitus temperatura 250°C usque ad 5 secundis. Crassitudo insulationis ab IEC 60502-2 definitur secundum aestimationem intentionis.

5. Vagina

PVC vaginatus: Propositum generale, flammeum retardatur, sumptus efficens. Apta tecta, ductum, et fossae officinae.
PE vaginantes: Melior umor resistentia, malle ad sepulturam directam et umida loca.
LSZH vaginatus: Fumus humilis et liberum halogen, cuniculis, substationibus sub tectis, et infrastructura publica.
Hoc productum utitur vagina PVC. Adfirmare utrum PVC acceptabile sit ignem project et environmental requisitis.

6. Installation Opera

Indoor: cables fercula, ductus, conclavia switchgear et substationes.
Fossorum et ductus funis: PVC involucrum tutelam praebet in destructione et contra damnum subsecutum.
Sepultura directa: Non commendata sine addito mechanica protectione. Utere fune armato vel aquaeductu.
Verticalis spicula: Confirm tensio trahens et firmamentum spacing.
Cuniculis et locis publicis: Perscriptio ignis perficiendi requisita; requiri LSZH.

7. tendentes Radii et Drum Longitudo

Radii flexionis minimum est typice 12-15 temporibus funem diametri exterioris ad institutionem staticam, et XX temporibus in destructione. Lego longi- orum secundum meatus longitudinem, articulorum numerum, limites transportandi, et modum institutionis.

8. signa

Denota applicabile vexillum: IEC 60502-2, GB/T 12706.2, BS 6622, VDE 0276-620, vel specialia requisita.

Technica cubits

Parameter	Unit	Typical Range / Bene
Vexillum	—	IEC 60502-2, GB/T 12706.2
Rated intentione U/U*	KV	3.6/6, 6/10, 8.7/15, 12/20, 18/30, 26/35
Maxime Ratio intentione um	KV	7.2, 12, 17.5, 24, 36, 42;
Numerus Cores	—	1, 3
Conductor	—	Aeris vel aluminium, Classis 1 vel 2, 25-630 mm²
Initium	—	XLPE (polyethylene crucis coniunctum)
Insulatio Temperature	°C	90 continuus; 250 circuitus brevis (max. 5 s).
Jactatio	—	PVC
Operating temperatus	°C	-40 ad XC conductor
Radius tendentes	—	≥12 diametrum exteriorem (staticum); ≥20 diametri exterioris (instructio)
Installation	—	Indoor, funis, ductus, fossa, switchgear, tray
stipare	—	Ferro vel tympanum ligneum; consuetudo tympanum longitudinis available

Nota: Specificationes variantur per aestimationem intentionis et magnitudinis conductoris. Confirmare mensuras ipsas et test notitia ante ordinationem.

Typical applications

Media intentione distributio retiacula in aedificiis et plantis industrialibus
Indoor switchgear ac TRANSFIGURATOR hospites
Funis ductus, fossae, fercula
Substantia potentiae auxiliaris in circuitibus
Cuniculum et infrastructurae illuminationis et potestatis copia
Renovabilis navitas collectionum systemata ubi PVC vaginatus acceptus est

MV Cable3

Applications

Et xlpe insulated potestatem funem late in:

Power Transmissus et distribution Systems
Subterraneis CAPULLIS pro urbana infrastructure
Industrial plantis et commercial aedificia
Renewable Energy Systems (Solaris, Ventus, etc.)

Product beneficia

Maximum diuturnitatem : xlpe Nulla praebet eximia mechanica vires, æstus resistentia, et longa-term perficientur in dura environments.
Energy efficientiam : disposito ad minimize industria damna, optimizing potentia distribution et reducing operational costs.
Aliquam Resistentia : PVC Tallis offert optimum praesidium contra humorem, UV radios, chemicals, et mechanica gerunt.
Salus ; conformis ad summum internationalis salutem et perficientur signa.

Single-Core, CU / xlpe / ATA / PVC aut al / XLX / ATA / PVC (Tabula XVII)

Conductor Nominal Regio	INOLENTIA	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	INOLENTIA	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.0	1.2	0.5	1.8	18	390	330	500
16	2.0	1.2	0.5	1.8	19	460	360	500
25	2.0	1.2	0.5	1.8	20	580	420	500
35	2.0	1.2	0.5	1.8	21	700	480	500
50	2.0	1.2	0.5	1.8	23	840	550	500
70	2.0	1.2	0.5	1.8	24	1,080	650	500
95	2.0	1.2	0.5	1.8	26	1,360	770	500
120	2.0	1.2	0.5	1.8	28	1,620	880	500
150	2.0	1.2	0.5	1.8	29	1,920	990	500
185	2.0	1.2	0.5	1.9	31	2,300	1,150	500
240	2.0	1.2	0.5	1.9	33	2,890	1,380	500
300	2.0	1.2	0.5	2.0	36	3,510	1,610	500
400	2.0	1.2	0.5	2.1	37	4,380	1,950	500
d
630	2.4	1.3	0.5	2.4	47	7.000	2,970	500

Tres-core, cu / xlpe / Sta / PVC aut al / XLIV / STA / PVC (Table XVIII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.0	1.2	0.5	1.8	28	910	720	500
16	2.0	1.2	0.5	1.9	29	1,120	820	500
25	2.0	1.2	0.5	1.9	32	1,480	1,000	500
35	2.0	1.2	0.5	2.0	35	1,840	1,170	500
50	2.0	1.2	0.5	2.1	38	1,300	1,410	500
70	2.0	1.2	0.5	2.2	43	3,390	2,100	500
95	2.0	1.2	0.5	2.3	46	4,330	2,530	500
120	2.0	1.3	0.5	2.4	50	5,180	2,910	500
150	2.0	1.4	0.5	2.6	54	6,180	3,370	500
185	2.0	1.4	0.5	2.7	57	7,120	3,920	500
240	2.0	1.5	0.5	2.8	63	9.350	4,750	400
300	2.0	1.6	0.5	3.0	68	11.340	5,550	300
400	2.0	1.8	0.5	3.3	76	14.220	6.830	300
500	2.2	1.9	0.5	3.5	84	17,850	8,380	250

3,6 / VI (7.2) KV, xlpe insulated unarmored PVC pessima potentia funem

Single-Core, Cu / xlpe / PVC aut al / XLIV / PVC (Table XIX)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	kg / km		m
10	2.5	1.8	15	320	260	500
16	2.5	1.8	18	390	290	500
25	2.5	1.8	20	500	340	500
35	2.5	1.8	21	610	400	500
50	2.5	1.8	22	750	450	500
70	2.5	1.8	24	970	550	500
95	2.5	1.8	25	1,250	660	500
120	2.5	1.8	27	1,500	760	500
150	2.5	1.8	28	1,790	860	500
185	2.5	1.9	30	2,150	1,000	500
240	2.6	1.9	33	2,770	1,250	500
300	2.8	2.0	35	3,400	1,500	500
400	3.0	2.1	39	4,280	1.850	500
500	3.2	2.2	43	5,400	2,280	500
630	3.2	2.4	47	6.830	2,800	500
800	3.2	2.5	51	8.570	3,400	400
1,000	3.2	2.6	56	10,590	4,110	300

Tres-Core, Cu / xlpe / PVC et al / XLX / PVC (Tabula XX)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	kg / km		m
10	2.5	1.9	33	980	790	500
16	2.5	2.0	35	1,190	890	500
25	2.5	2.1	38	1,560	1,080	500
35	2.5	2.2	40	1,930	1,270	500
50	2.5	2.3	43	2,370	1,480	500
70	2.5	2.4	47	3,110	1,820	500
95	2.5	2.5	51	4,000	2,200	500
120	2.5	2.6	54	4,820	2,550	500
150	2.5	2.7	58	5,770	2,970	500
185	2.5	2.8	61	6,960	3,460	500
240	2.6	3.0	68	8.940	4,340	400
300	2.8	3.2	73	10,980	5.190	300
400	3.0	3.5	81	13.820	6.440	250
500	3.2	3.7	90	17,390	7.910	200

3,6 / VI (7.2) KV, xlpe insulated filum armis PVC pusillae potestatem funem

Single-Core, Cu / xlpe / Awa / PVC Oral / xlpe / Awa / PVC (Table XXI)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	0.9	1.8	22	610	550	500
16	2.5	1.2	1.6	1.8	24	680	580	500
25	2.5	1.2	1.6	1.8	25	810	660	500
35	2.5	1.2	1.6	1.8	26	940	730	500
50	2.5	1.2	1.6	1.8	27	1,100	810	500
70	2.5	1.2	1.6	1.8	29	1,350	930	500
95	2.5	1.2	1.6	1.9	31	1,670	1,080	500
120	2.5	1.2	1.6	1.9	32	1,950	1,200	500
150	2.5	1.2	1.6	2.0	34	2,270	1,350	500
185	2.5	1.2	2.0	2.1	37	2,770	1,620	500
240	2.6	1.2	2.0	2.2	40	3,440	1,930	500
300	2.8	1.2	2.0	2.2	42	4,120	2,210	500
400	3.0	1.3	2.5	2.4	47	5,250	2,820	500
500	3.2	1.3	2.5	2.5	51	6,450	3,340	500
630	3.2	1.4	2.5	2.6	55	7,990	3,950	400

Tres-Core, Cu / xlpe / SWA / PVC et al / xlpe / SWA / PVC (Table XXII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	2.0	2.1	40	2,310	2,120	500
16	2.5	1.2	2.0	2.2	42	2,600	2,290	500
25	2.5	1.2	2.0	2.3	45	3,080	2,600	500
35	2.5	1.3	2.5	2.4	48	3,950	3,280	500
50	2.5	1.3	2.5	2.5	54	4,530	3,630	500
70	2.5	1.4	2.5	2.6	55	5,510	4,210	500
95	2.5	1.5	2.5	2.8	59	6,660	4,860	500
120	2.5	1.5	2.5	2.9	63	7,630	5,360	400
150	2.5	1.6	2.5	3.0	66	8,800	6,000	400
185	2.5	1.7	3.15	3.2	72	11,500	6.670	300
240	2.6	1.8	3.15	3.4	78	13,480	8.870	250
300	2.8	1.9	3.15	3.6	84	15,920	10,130	200
400	3.0	2.0	4.0	3.9	94	21,300	12,590	200
500	3.2	2.1	4.0	4.1	103	25.090	15,610	200

3,6 / VI (7.2) KV, xlpe insulatas tape armis PVC pusillae potestatem funem

Single-Core, Cu / xlpe / ATA / Pvcor Al / xlpe / Ata / PVC (Table XXIII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Arma Filum Magnitudo	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Arma Filum Magnitudo	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	0.5	1.8	22	530	460	500
16	2.5	1.2	0.5	1.8	23	600	500	500
25	2.5	1.2	0.5	1.8	24	730	570	500
35	2.5	1.2	0.5	1.8	25	850	630	500
50	2.5	1.2	0.5	1.8	26	1,000	700	500
70	2.5	1.2	0.5	1.8	28	1,240	820	500
95	2.5	1.2	0.5	1.8	30	1,540	950	500
120	2.5	1.2	0.5	1.8	31	1,820	1,080	500
150	2.5	1.2	0.5	1.9	33	2,120	1,200	500
185	2.5	1.2	0.5	1.9	35	2.520	1,370	500
240	2.6	1.2	0.5	2.0	37	3,180	1,670	500
300	2.8	1.2	0.5	2.1	40	3,850	1,950	500
400	3.0	1.3	0.5	2.3	44	4,800	2,370	500
500	3.2	1.3	0.5	2.4	48	5,960	2,840	500
630	3.2	1.4	0.5	2.5	52	7,450	3,410	600

Tres-core, cu / xlpe / sta / pvcor al / xlpe / sta / pvc (mensam XXIV)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
10	2.5	1.2	0.2	2.0	37	1,330	1,140	500
16	2.5	1.2	0.5	2.1	40	1,580	1,580	500
25	2.5	1.2	0.5	2.2	42	2,310	1,880	500
35	2.5	1.3	0.5	2.3	45	2,760	2,090	500
50	2.5	1.3	0.5	2.4	48	3,260	2,360	500
70	2.5	1.4	0.5	2.5	52	4,100	2,810	500
95	2.5	1.5	0.5	2.7	56	5.10	3,310	500
120	2.5	1.5	0.5	2.8	60	5,010	3,750	400
150	2.5	1.6	0.5	2.9	63	7,050	4,250	400
185	2.5	1.7	0.5	3.0	67	9.320	4,820	400
240	2.6	1.8	0.5	3.2	73	10,530	5,920	300
300	2.8	1.9	0.5	3.4	79	12,730	6.940	300
400	3.0	2.0	0.8	3.7	89	16.620	9.240	200
500	3.2	2.1	0.8	4.0	98	20,550	11,070	200

VI ~ 30kv xlpe insulatas potestatem cables

Hoc productum utitur Finland Nextrom (Nokia) Tres Layer Co-extrusionem productio linea ad vestibulum eget crucem-vinculum.
Convenitur certa impositionem medium voltage linea.
In perficientur de cables secundum stipulate IEC (VI) DII.

Products specificationem

Exemplar		Nomen
Cu / xlpe / PVC	AL / xlpe / PVC	Aeris aut Aluminium Conductor xlpe insulated et PVC tondet potestatem funem
Cu / xlpe / pe	Al / xlpe / Pe	Aeris aut Aluminium Conductor xlpe insulated et PE p tregithy potestatem funem
Cu / xlpe / sta / PVC	AL / xlpe / STA / PVC	Aeris aut aluminium conductor xlpe insulatas ferro tape armis PVC pusillae potestatem funem
Cu / xlpe / sta / pe	AL / xlpe / STA / PE	Aeris aut Aluminium Conductor xlpe insulatas ferro tape armis PE purus potestatem funem
Cu / xlpe / swa / PVC	Al / xlpe / SWA / PVC	Aeris aut Aluminium Conductor xlpe insulated ferro filum armis PVC pessima potestate funem
Cu / xlpe / SWA / PE	Al / xlpe / SWA / PE	Aeris aut aluminium conductor xlpe insulated ferro filum rmored pe sheathed potestatem funem
Cu / xlpe / cWl / PE	Al / xlpe / cWl / PE	Aeris aut Aluminium Conductor xlpe insulated comprehensive IMPERVIUS Suspendisse potestatem cable

Range of application

Exemplar		Range of application
Cu / xlpe / PVC	AL / xlpe / PVC	Conveniens impositis domesticas et foris, fixa in bracket in cuniculum et potest trita per concretum pipe aut in cable fossa sepulta directe soluta. Et funem non sustinere pressura, sed sino quodam quanta radialis tractus.
Cu / xlpe / pe	Al / xlpe / Pe
Cu / xlpe / sta / PVC	AL / xlpe / STA / PVC	In humo buried, funem potest resistere aliqua pressura, sed non poterit sustinere magnam tensile vi.
Cu / xlpe / sta / pe	AL / xlpe / STA / PE
Cu / xlpe / swa / PVC	Al / xlpe / SWA / PVC
Cu / xlpe / SWA / PE	Al / xlpe / SWA / PE
Cu / xlpe / cWl / PE	Al / xlpe / cWl / PE	Est usus ad aqua resistente postulationem de exteriore iacuit de funem

Oriente Energy

Electrical Engineering

VI / 6kv, VI / X (XII) KV, xlped insulated unarmored pvc pmcc tondet potestatem funem unum-core, cu / xlpe / PVC et al / xlpe / xlpe (mensa XXV)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	kg / km		m
16	3.4	1.8	20	450	350	500
25	3.4	1.8	21	560	400	500
35	3.4	1.8	22	680	460	500
50	3.4	1.8	24	810	520	500
70	3.4	1.8	25	1,050	620	500
95	3.4	1.8	27	1,320	730	500
120	3.4	1.8	28	1,580	840	500
150	3.4	1.9	30	1,880	960	500
185	3.4	1.9	32	2,250	1,100	500
240	3.4	2.0	34	2,870	1,350	500
300	3.4	2.1	37	3,490	1,580	500
400	3.4	2.2	40	4,350	1,920	500
500	3.4	2.3	44	5,440	2,320	500
630	3.4	2.4	48	6.860	2,830	500
800	3.4	2.5	52	8,600	3,430	400
1.000	3.4	2.6	56	10,630	4,150	300

Tres-Core, Cu / xlpe / PVC et al / XLX / PVC (Table XXVI)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Pondus approx.cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	kg / km		m
16	3.4	2.1	39	1,410	1,110	500
25	3.4	2.2	42	1,800	1,320	500
35	3.4	2.3	45	2,170	1,500	500
50	3.4	2.4	47	2,630	1,730	500
70	3.4	2.5	51	3,400	2,110	500
95	3.4	2.6	55	4,310	2,510	500
120	3.4	2.7	58	5,150	2,860	500
150	3.4	2.9	62	6,100	3,300	500
185	3.4	3.0	66	7,310	3,810	500
240	3.4	3.1	71	9.290	4,680	400
300	3.4	3.3	76	11.240	5,450	300
400	3.4	3.5	83	14.040	6,660	250
500	3.4	3.7	91	17.530	8.050	200

VI / 6kv, VI / X (XII) Kv, xlped insulated filum armis PVC pusillae potestatem cable

Single-Core, Cu / xlpe / Awa / PVC aut al / xlpe / awa / PVC (Tabula XXVII)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
16	3.4	1.2	1.6	1.8	26	770	670	500
25	3.4	1.2	1.6	1.8	27	910	750	500
35	3.4	1.2	1.6	1.8	28	1,040	820	500
50	3.4	1.2	1.6	1.8	29	1,190	900	500
70	3.4	1.2	1.6	1.9	31	1,470	1,040	500
95	3.4	1.2	1.6	2.0	33	1,780	1,190	500
120	3.4	1.2	2.0	2.0	35	2,150	1,410	500
150	3.4	1.2	2.0	2.1	37	2,480	1,560	500
185	3.4	1.2	2.0	2.1	39	2,890	1,730	500
240	3.4	1.2	2.0	2.2	41	3,570	2,050	500
300	3.4	1.2	2.0	2.3	44	4,230	2,330	500
400	3.4	1.3	2.5	2.4	48	5,320	2,890	500
500	3.4	1.3	2.5	2.5	52	6,500	3,380	500
630	3.4	1.4	2.5	2.6	56	8.020	3,990	400

Tres-Core, Cu / xlpe / SWA / PVC et al / XL / SWA / PVC (Table XXVIII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
16	3.4	1.3	2.5	2.4	47	3,700	2,700	500
25	3.4	1.3	2.5	2.5	50	3,900	3,430	500
35	3.4	1.3	2.5	2.6	53	4,430	3,770	500
50	3.4	1.4	2.5	2.7	56	5.080	4,190	500
70	3.4	1.5	2.5	2.8	60	6,050	4,750	500
95	3.4	1.5	2.5	2.9	64	7,180	5,380	500
120	3.4	1.6	2.5	3.0	67	8.230	5,960	400
150	3.4	1.7	3.15	3.2	72	10,100	6,580	300
185	3.4	1.7	3.15	3.3	76	11,610	8,110	300
240	3.4	1.8	3.15	3.5	82	14.10	9.510	250
300	3.4	1.9	3.15	3.7	87	16,420	10,630	200
400	3.4	2.0	4.0	4.0	96	21,700	12,880	200
500	3.4	2.2	4.0	4.2	104	25,280	15,800	200

VI / 6kv, VI / X (XII) Kv, xlpe insulatas tape armis PVC pusilla

Single-Core, CU / xlpe / ATA / PVC aut al / XLX / ATA / PVC (Tabula XXIX)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
16	3.4	1.2	0.5	1.8	25	680	580	500
25	3.4	1.2	0.5	1.8	26	810	650	500
35	3.4	1.2	0.5	1.8	27	940	720	500
50	3.4	1.2	0.5	1.8	28	1,090	790	500
70	3.4	1.2	0.5	1.9	30	1,350	920	500
95	3.4	1.2	0.5	1.9	32	1,650	1,060	500
120	3.4	1.2	0.5	2.0	33	1,940	1,190	500
150	3.4	1.2	0.5	2.0	35	2,240	1,320	500
185	3.4	1.2	0.5	2.1	37	2,650	1,500	500
240	3.4	1.2	0.5	2.1	39	3,290	1,770	500
300	3.4	1.2	0.5	2.2	41	3,940	2,030	500
400	3.4	1.3	0.5	2.3	45	4,860	2,430	500
500	3.4	1.3	0.5	2.4	49	5,990	2,880	500
630	3.4	1.4	0.5	2.5	52	7,480	3,450	500

Tres-core, cu / xlpe / sta / PVC aut al / xlpe / sta / PVC (XXX mensa)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
16	3.4	1.3	0.2	2.3	44	2,220	1,900	500
25	3.4	1.3	0.5	2.4	47	2,660	2,180	500
35	3.4	1.3	0.5	2.5	50	3,110	2,440	500
50	3.4	1.4	0.5	2.6	53	3,650	2,750	500
70	3.4	1.5	0.5	2.7	56	4,510	3,220	500
95	3.4	1.5	0.5	2.8	60	5,510	3,710	500
120	3.4	1.6	0.5	2.9	64	6,450	4,180	500
150	3.4	1.7	0.5	3.1	68	7,500	4,700	400
185	3.4	1.7	0.5	3.2	71	8.830	5,330	400
240	3.4	1.8	0.5	3.3	77	10,960	6,360	300
300	3.4	1.9	0.5	3.5	82	13.090	7,300	250
400	3.4	2.0	0.8	3.8	91	16.910	9.530	200
500	3.4	2.2	0.8	4.0	99	20,720	11,250	200

8,7 / 10kv, 8,7 / XV (17.5) KV, xlpe insulated unarmored PVC pmcs potestatem funem

Single-Core, Cu / xlpe / PVC et al / XLIV / PVC (XXXI Table)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	kg / km		m
25	4.5	1.8	24	640	480	500
35	4.5	1.8	25	760	540	500
50	4.5	1.8	26	900	610	500
70	4.5	1.8	28	1,140	710	500
95	4.5	1.8	29	1,420	830	500
120	4.5	1.9	31	1,700	950	500
150	4.5	1.9	32	1,990	1,070	500
185	4.5	2.0	34	2,380	1,230	500
240	4.5	2.1	37	3,010	1,490	500
300	4.5	2.1	39	3,620	1,720	500
400	4.5	2.2	42	4,490	2,070	500
500	4.5	2.3	46	5,600	2,480	500
630	4.5	2.5	50	7,050	3,010	500
800	4.5	2.6	54	8,800	3,630	400
1,000	4.5	2.7	58	10,850	4,370	300

Tres-core, cu / xlpe / PVC et al / xlpe / pvc (XXXII)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	kg / km		m
25	4.5	2.4	47	2,100	1,620	500
35	4.5	2.5	50	2,510	1,840	500
50	4.5	2.6	52	2,980	2,080	500
70	4.5	2.7	56	3,760	2,470	500
95	4.5	2.8	60	4,700	2,900	500
120	4.5	2.9	63	5,590	3,320	500
150	4.5	3.0	67	6.560	3,760	500
185	4.5	3.1	71	7,800	4,300	400
240	4.5	3.3	76	9.820	5,220	300
300	4.5	3.5	81	11,800	6,010	300
400	4.5	3.7	88	14.620	7,250	250
500	4.5	3.9	96	18,150	8.680	200

VIII .7 / 10kv, 8,7 / XV (17.5) KV, xlpe insulated filum armis PVC pusillae potestatem funem

Single-Core, Cu / xlpe / Awa / PVC Oral / xlpe / Awa / PVC (Table XXXIII)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
25	4.5	1.2	1.6	1.8	29	1,020	860	500
35	4.5	1.2	1.6	1.9	30	1,170	950	500
50	4.5	1.2	1.6	1.9	32	1,340	1,040	500
70	4.5	1.2	1.6	2.0	34	1,640	1,190	500
95	4.5	1.2	2.0	2.1	36	2,020	1,430	500
120	4.5	1.2	2.0	2.1	38	2,310	1,570	500
150	4.5	1.2	2.0	2.2	39	2,660	1,740	500
185	4.5	1.2	2.0	2.2	41	3,070	1,920	500
240	4.5	1.2	2.0	2.3	44	3,750	2,240	500
300	4.5	1.3	2.5	2.4	47	4,590	2,690	500
400	4.5	1.3	2.5	2.5	50	5,550	3,120	500
500	4.5	1.4	2.5	2.6	51	6.750	3,640	500
630	4.5	1.4	2.5	2.7	58	8,280	4,240	400

Tres-Core, Cu / xlpe / SWA / PVC aut al / xlpe / SWA / PVC (Table XXXIV)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Arma Filum Magnitudo	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Arma Filum Magnitudo	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
25	4.5	1.4	2.5	2.7	55	4,560	4,080	500
35	4.5	1.4	2.5	2.8	58	5.080	4,410	500
50	4.5	1.5	2.5	2.9	61	5.740	4,840	500
70	4.5	1.6	2.5	3.0	65	6,770	5,480	500
95	4.5	1.6	2.5	3.1	69	7,890	6,100	400
120	4.5	1.7	3.15	3.2	74	10,900	6,700	400
150	4.5	1.8	3.15	3.4	77	11.030	8.220	300
185	4.5	1.8	3.15	3.5	81	12,490	8.980	250
240	4.5	1.9	4.0	3.7	89	17,500	10,440	250
300	4.5	2.0	4.0	3.9	94	20,100	12,130	200
400	4.5	2.1	4.0	4.1	101	23,600	13,970	200

8,7 / 10kv, 8,7 / XV (17.5) KV, xlpe insulatas tape armis PVC pmc Power Cable

Single-Core, Cu / xlpe / ATA / PVC aut al / xlpe / ATA / PVC (Table XXXV)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime altiore diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime altiore diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
25	4.5	1.2	0.5	1.8	28	910	760	500
35	4.5	1.2	0.5	1.8	29	1,050	830	500
50	4.5	1.2	0.5	1.9	30	1,210	920	500
70	4.5	1.2	0.5	1.9	32	1,470	1,050	500
95	4.5	1.2	0.5	2.0	34	1,790	1,200	500
120	4.5	1.2	0.5	2.0	35	2,070	1,320	500
150	4.5	1.2	0.5	2.1	37	2,400	1,470	500
185	4.5	1.2	0.5	2.1	39	2,800	1,640	500
240	4.5	1.2	0.5	2.2	41	3,460	1,940	500
300	4.5	1.3	0.5	2.3	44	4,160	2,230	500
400	4.5	1.3	0.5	2.4	47	5.050	2,620	500
500	4.5	1.4	0.5	2.5	51	6.220	3,100	500
630	4.5	1.4	0.5	2.6	55	7,710	3,670	500

Tres-core, cu / xlpe / sta / PVC et al / xlpe / sta / PVC (XXXVI Table)

Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Proxime. PRAETORIUM Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
25	4.5	1.4	0.5	2.6	52	3,120	2,640	500
35	4.5	1.4	0.5	2.6	55	3,570	2,900	500
50	4.5	1.5	0.5	2.7	58	4,120	3,220	500
70	4.5	1.6	0.5	2.9	62	5.050	3,750	500
95	4.5	1.6	0.5	3.0	66	6,070	4,270	500
120	4.5	1.7	0.5	3.1	69	7.040	4,770	500
150	4.5	1.8	0.5	3.2	73	8,120	5,310	400
185	4.5	1.8	0.5	3.3	77	9.440	5.940	300
240	4.5	1.9	0.5	3.5	83	11,660	7,050	300
300	4.5	2.0	0.8	3.7	89	14,600	8.810	250
400	4.5	2.1	0.8	4.0	96	17,760	10,370	200
500	4.5	2.3	0.8	4.2	105	21,620	12,150	200

12/20 (XXIV) KV, xlpe insulated unarmored PVC pusillae potestatem funem

Single-Core, Cu / xlpe / PVC aut al / XLIV / PVC (XXXVII mensa)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	kg / km		m
35	5.5	1.8	27	840	620	500
50	5.5	1.8	28	990	690	500
70	5.5	1.9	30	1,230	800	500
95	5.5	1.9	31	1,530	940	500
120	5.5	2.0	33	1,810	1,060	500
150	5.5	2.0	35	2,110	1,190	500
185	5.5	2.1	36	2,510	1,360	500
240	5.5	2.1	39	3,130	1,610	500
300	5.5	2.2	41	3,760	1,860	500
400	5.5	2.3	44	4,650	2,220	500
500	5.5	2.4	48	5.760	2,650	500
630	5.5	2.5	52	7,210	3,180	500
800	5.5	2.6	56	8.980	3,800	400
1,000	5.5	2.8	61	11,060	4,580	300

Tres-core, cu / xlpe / PVC aut al / xlpe / pvc

(XXXVIII mensa)

Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Proxime. Pondus cable		Vexillum longitudinem per Tympanum
Conductor Nominal Regio	SINTULATIO	Exteriore vagina crassitudine	Proxime. Altiore Diameter	Aes	Aluminium	Vexillum longitudinem per Tympanum
mm²	mm	mm	mm	kg / km		m
35	5.5	2.6	54	2,850	2,080	500
50	5.5	2.7	57	3,340	2,450	500
70	5.5	2.9	61	4,150	2,850	500
95	5.5	3.0	65	5.10	3,310	500
120	5.5	3.1	68	5,990	3,730	500
150	5.5	3.2	72	6.980	4.180	500
185	5.5	3.3	75	8.240	4,740	400
240	5.5	3.5	81	10,310	5,700	300
300	5.5	3.6	86	12,350	6,570	300
400	5.5	3.8	93	15.220	7.830	200
500	5.5	4.1	101	18,800	9.320	200

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
35	5.5	1.5	2.5	2.9	63	5,680	5,010	500
50	5.5	1.6	2.5	3.0	66	6.370	5,480	500
70	5.5	1.7	2.5	3.1	70	7,370	6,070	400
95	5.5	1.7	3.15	3.3	75	9.400	7,600	300
120	5.5	1.8	3.15	3.4	79	10,530	8,270	300
150	5.5	1.8	3.15	3.5	82	11.740	8.940	300
185	5.5	1.9	3.15	3.7	86	13,350	9.850	250
240	5.5	2.0	4.0	3.9	94	18.000	11.820	200
300	5.5	2.1	4.0	4.0	99	20,500	13,080	200
400	5.5	2.2	4.0	4.3	106	23.310	15,930	200

12/20 (XXIV) KV, xlpe insulated filum armis PVC pusillae potestatem funem

Single-Core, Cu / xlpe / Awa / PVC Oral / xlpe / Awa / PVC (Table XXXIX)

Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Proxime. Pondus cable		Vexillum Longitudo per Tympanum
Conductor Nominal Regio	SINTULATIO	Approx.inner covering Crassities	Armis mole mole	Exterior Vagina Crassities	Proxime. DIGNUS	Aes	Aluminium	Vexillum Longitudo per Tympanum
mm²	mm	mm	mm	mm	mm	kg / km		m
35	5.5	1.2	1.6	1.9	32	1,290	1,070	500
50	5.5	1.2	2.0	2.0	35	1,550	1,250	500
70	5.5	1.2	2.0	2.1	37	1,840	1,420	500
95	5.5	1.2	2.0	2.1	38	2,160	1,570	500
120	5.5	1.2	2.0	2.2	40	2,470	1,730	500
150	5.5	1.2	2.0	2.2	41	2,810	1,890	500
185	5.5	1.2	2.0	2.3	43	3,240	2,090	500
240	5.5	1.3	2.5	2.4	47	4,100	2,580	500
300	5.5	1.3	2.5	2.5	49	4,800	2,890	500
400	5.5	1.4	2.5	2.6	53	5,780	3,350	500
500	5.5	1.4	2.5	2.7	57	6.970	3,850	500
630	5.5	1.5	2.5	2.8	60	8.540	4,500	400

Tres-Core, Cu / xlpe / SWA / Pvcloral / xlpe / SWA / PVC (Table XL)

Productum compositionem

Conductor: factum ex summus qualitas aeris conductor, quod est optimum conductivity, cursus humilis resistentia et altum transmissionem efficientiam.
Stuulationem layer: factum ex crucis, coniunctum polyethylene, id est bonum electrica proprietatibus et altum temperatus resistentia, ensuring stabilitatem durante diu terminus.
THEH materia: et funem factum est de Aluminium corrugated vagina in foris, quae habet bonum mechanica tutela et potest ne externa corporalis damnum.
Additional Protective Layer: Quidam exempla potest eligere PVC vagina providere additional IMPERVIUS et eget corrosio praesidium.

Quare eligere nobis?

Stricte qualis imperium: providere plenus-processus qualis imperium a productio ad partum ut omnis uber occurrat summum signa.
Global Business Support: Habemus wide foro network in multis regionibus et regionibus, et potest Respondeo ad mos necessitatibus in opportune modo et providere ieiunium post-Sales servitium.

FAQs

Q: Numquid Securus install?

A: Hoc funem adoptat mensuris, simplex installation, et apta variis potentia systems. Nam propria environments, vos can eligere oportet vagina secundum materiam secundum necessitates.

Q: Quid est ministerium vitae huius productum?

A: Ob usu summus qualitas xlpe velit et aluminium corrugated vagina nostra funem products habere servitium vitae plus quam XX annis et potest operari stabiliter in altum temperatus, altus humiditas et canired in altum tortor, altus humiditas et dura ambitus.

priorem:

deinde:

*quin Code
