Concentricis LV cable
Code: c Oncentric LV funem.
Signa: IEC60228, IEC60502.
Construction: Aeris aut Aluminium Conductor, aeris filum screen concentric cable cum PVC
Vallum PVC vagina .
Application : nam certum installation in terram
aut in Ducts.The concentric conductor Serves ut
screen vel tutela Earthing Conductor.
Dimensionem cable
Numerum cororum × Nominal Cross-section / Crucis-sectioni aeris filum screen | No.of Conductor STRANS | Diameter ex | Initium Crassities | Nomina crassitudine vagina | Proxime. DIGNUS | Approx.Overall pondus | Vexillum Longitudo per Tympanum | |
Aes | Aluminium | |||||||
mm² | mm | mm | mm | mm | kg / km | m | ||
I × X / X | 7 | 1.35 | 1.0 | 1.4 | 12.1 | 278.4 | 215.3 | 5,000 |
I × XVI / XVI | 7 | 1.73 | 1.0 | 1.4 | 13.7 | 401.9 | 300.9 | 5,000 |
I × XXV / XXV | 7 | 2.16 | 1.2 | 1.4 | 15.4 | 593.8 | 436.0 | 5,000 |
I × XXXV / XXXV | 7 | 2.58 | 1.2 | 1.4 | 16.8 | 792.7 | 571.7 | 5,000 |
I × L / L | 19 | 1.84 | 1.4 | 1.5 | 19.3 | 1,108.7 | 793.0 | 5,000 |
I × LXX / LXX | 19 | 2.18 | 1.4 | 1.5 | 21.5 | 1,553.3 | 1,11.3 | 4,000 |
I × XCV / XCV | 19 | 2.58 | 1.6 | 1.6 | 24.5 | 2,019.8 | 1,419.9 | 3,500 |
III × X / X | 7 | 1.35 | 1.0 | 1.8 | 20.0 | 635.2 | 443.2 | 5,000 |
III × XVI / XVI | 7 | 1.73 | 1.0 | 1.8 | 22.7 | 902.0 | 594.9 | 4,000 |
III × XXV / XXV | 7 | 2.16 | 1.2 | 1.8 | 26.2 | 1,328.1 | 848.2 | 3,000 |
III × XXXV / XXXV | 7 | 2.58 | 1.2 | 1.8 | 28.7 | 1,746.6 | 1,074.8 | 2,500 |
III × L / L | 19 | 1.84 | 1.4 | 1.9 | 33.2 | 2,423.7 | 1,464.0 | 1,800 |
III × LXX / LXX | 19 | 2.18 | 1.4 | 2.0 | 37.4 | 3,345.5 | 2,001.9 | 1,500 |
III × XCV / XCV | 19 | 2.58 | 1.6 | 2.2 | 42.9 | 4,414.8 | 2,591.4 | 1,000 |
