H05VVH2, F
CCC / 500v
Code
: Ho5vvh2, F
Latin: TS (IX) DCCLX, IEC: CCXXVII, VDE CCLXXXI, BS (VI) D
Construction: I-flexibilia aeris conductor
II-PVC Nulla
3 Pvcouter vagina
Application : in dry.damp et infectum locus cum lux mechanica passiones ut flexibilia connectens cables. Cum plana figura, quod adhibetur ad manus instrumenta et domum tenere adjumenta.
Technical data: max.operating temperatus LXX ℃
Short Ciruit temperatus CLX ℃
Num. et coros et nominis crucis sectionem | Numero et dia.of fila | Crassitudo initium | Approx.od | Conductor DC Ad XX ℃ resistentia | Proxime. Summa Pondus | Max.curent Portatio Capacitas ad XXX ℃ | ||
mm² | No. × mm | min | max | max.mm | Ω / km | Kg / km | Pipe | Aera |
II × 0,75 | XXII × 0.20 | 0.6 | 0.8 | 4.00 × 6.40 | 26.0 | 37.0 | 13 | |
II × I | XXX × 0.20 | 0.6 | 0.8 | 4.10 x 6.60 | 19.5 | 61.1 | 12 | 16 |
II × 1.5 | XXVII × 0,25 | 0.7 | 0.8 | 4.60 × 7.60 | 13.3 | 85.0 | 16 | 20 |
II × 2.5 | XLV × 0,25 | 0.8 | 1.0 | 5.70 × 9.40 | 7.98 | 128 | 21 | 27 |
II × IV | L 0,30 × | 0.8 | 1.1 | 6.40 × 10.6 | 4.95 | 185 | 27 | 36 |
III × 0.75 | XXII × 0.20 | 0.6 | 0.8 | 4.00 × 8,80 | 26.0 | 65.0 | - | 13 |
III × I | XXX × 0.20 | 0.6 | 0.8 | 4.10 × 9.10 | 19.5 | 77.0 | 12 | 16 |
III × 1.5 | XXVII × 0,25 | 0.7 | 0.9 | 4.70 × 10.50 | 13.3 | 104 | 16 | 20 |
III × 2.5 | XLV × 0,25 | 0.8 | 1.1 | 5.90 × 13.30 | 7.98 | 159 | 21 | 27 |
III × IV | L 0,30 × | 0.8 | 1.2 | 6.60 × 15.60 | 4.95 | 228 | 27 | 36 |
