YJV32
LAT CABLE 0.6/1kV Solidus Copper Conductor Indoor Flat Cable (Model: MYP-0-38-0-66KV-3x35-1x16) summus effectus est, funis electrica flexibilis ad certae translationis potentiae indagines destinata:
Residentialibus aedificia
Commercial complexa
Industrial facilities
Designatum et fabricatum ab Oriente Energy Electrical Engineering Co., Ltd., incepti professionalis specialiter in:
Systema electrica R&D
Virtus engineering
Energy solutiones
Funis hic salus internationalis et signa perficiendi occurrit:
| Standard | Description |
|---|---|
| Ty (IX) DCCLX | Turcorum vexillum ad PVC insulatas rudentes |
| IEC 60227 | International vexillum pro PVC insulatas retinacula |
| VDE 0281 | Germanica vexillum ad PVC insulatas retinacula |
| BS 6500 | British vexillum ad flexibiles rudentes |
| Pluma | Descriptio |
|---|---|
| Plana design | Servat spatium et simpliciores institutionem in stricta areas |
| Conductor aeris solidum | Princeps conductivity et certa perficientur praestat |
| Rated voltage | 0.6/1 kv - apta ad potentiam circuitus |
| Robustum constructione | Designed for long-term amet use |
Industriae plantae
Commercial aedificia
Residentiales complexa
Switching stationes
Imperium Panel
| Feature | Description | Beneficium |
|---|---|---|
| Magnum Conductivity | Corculum aeris solidum cum resistentia humili DC (eg, 18.1 Ω/km pro 1 mm²) | Regium industria damnum (I²R) |
| Aucta salus | Nulla et Dual PVC vaginam exteriorem | Protegit contra lacus, pulverem, humidum et ictum levium |
| DESPRIMENTUM | Plana profile vicium facile in stricta spatia | Specimen pro meatibus, ferculis, et ductibus occultis |
| Global Obsequium | IEC, VDE, BS signa nuntiata | Apta pro exportandis et ordinatis inceptis |
| Flexibile Application | Opera ad amet wiring, plantae industriales, stationes mutandi | Reduces cable inventarium |
| ECFECTUS | Leve ac facile install | Demittit naves laboris sumptibus |
| Versatility | Available in 2-core and 3-core (1-4 mm) | Matches accendit ad vim onus requisita |
| Material | Description | |
|---|---|---|
| Conductor | Aes solidum (Class 1, IEC, 60228); | Princeps conductivity, humilis resistentia, facilis terminatio |
| Initium | PVC Type A | Color-coded (brunneae / caeruleae vel brunneae / caeruleae/ viridi-flavae) |
| Filler | PVC vel non-hygroscopic materia | Figuram tenet et integritas mechanica |
| Exterior Vagina | PVC | Plana profile, UV stabiliuntur, flammea retardant |
| Cores × mm² | Filum Diae. (mm) | Insulation Creber. (mm) | Sheath Thick. (mm) | DC Res. @20°C (Ω/km) | Pondus (kg/km) | Current (Pipe) A | Current (Aeris) A |
|---|---|---|---|---|---|---|---|
| 2 1.0 | 1.1 | 0.6 | 0.8 | 18.1 | 50.0 | — | 19 |
| II × 1.5 | 1.35 | 0.7 | 0.8 | 12.1 | 66.0 | 32 | 20 |
| II × 2.5 | 1.73 | 0.8 | 1.0 | 7.41 | 104 | 42 | 20 |
| 2 4.0 | 2.19 | 0.8 | 1.1 | 4.61 | 143 | 54 | 20 |
| 3 1.0 | 1.1 | 0.6 | 0.8 | 18.1 | 73.0 | — | 20 |
| III × 1.5 | 1.35 | 0.7 | 0.9 | 12.1 | 101 | 26 | 20 |
| III × 2.5 | 1.73 | 0.8 | 1.1 | 7.41 | 158 | 34 | 20 |
| 3 4.0 | 2.19 | 0.8 | 1.2 | 4.61 | 216 | 44 | 20 |
| Parameter | Precium |
|---|---|
| Maximum conductor continua temperatus | 70°C |
| Maximum breve spatium temperatus (≤5s) | 160°C |
| Minimum institutionem temperatus | 0°C (pre-calidum si infra 0°C) |
| Ambiens operating range | -5°C ad +50°C |
| Parameter | valorem | vexillum |
|---|---|---|
| Rated voltage (U₀/U) | 0.6/1 kV | IEC 60227 |
| Test voltage | 3 kV AC pro 5 min | IEC 60227 |
| Nulla resistentia | ≥ 10 MΩ·km @20°C | IEC 60227 |
| Flamma retardatio | auto-extinguere | 60332-1 IEC |
Residentiales: domus wiring, illuminans, potentia decursibus
Commercial: officia, scruta, hotels, hospitalia
Educational: scholae, academiae, labs
Machinery: motores, soleatus, TRADUCTOR
Tabulata control: PLC wiring, instrumentation
Commutatio stationum: potestas auxiliaris, circuitus imperium
Planta electrification: officina area distribution
Funis ductus, fercula, specus, raceways inclusae
In ductibus seu manicis addito mechanica praesidio
| Ratio | Explicatio |
|---|---|
| Reliability | Aeris solidum + PVC constructionem firmum efficit 0.6/1kV effectus |
| Certified Quality | Plene obsequentes signis IEC, VDE, BS, TS |
| ECFECTUS | Leve consilium naves et laboris costs reduces |
| Versatility | 2-core & 3-core (1-4 mm) pro multiplicibus applicationibus |
| Expertise fabrica | Subnixum Orientis Energy scriptor 15+ annos experientia |
| Salus | Flamma retardans PVC + duplex velit |
| Installation Type | Minimum tendentes Radii |
|---|---|
| Certa institutionem | VI altiore diametro |
| Flexibile usus | X altiore diametro |
Maximum: 50 N/mm² conductoris crucis-sectionis
Utere trahens tenet vel rhoncus socks
Excute ne incidenter diligenter
Utere congruis terminalibus (anulus, furca, paxillus)
Noli nimis torque
Maximum imple: 40% (NEC/IEC)
Usus maior ductibus ad diu currit vel plures rudentes
| Pluma | LAT Flat Cable (Slid Copper) | Round PVC Cable (stranded) | Flat TPS Cable (Australia) |
|---|---|---|---|
| Conductor type | Solidum aeris (Class 1). | Aes destitutum (Class 5/6) | Aut solidum subductis |
| Profile | Flat | Circum | Flat |
| Spatium efficientiam | Praeclarus | Pauperes | Bonum |
| Terminatio otium | Securus | Moderor | Securus |
| Mollitia | Moderor | Altum | Moderor |
| Cost | Humilis | Medium | Medium |
| Typicam applicationem | Fixum amet wiring | Portable apparatibus | Fixum wiring (AU/NZ) |
| Standard | Description | Status |
|---|---|---|
| IEC 60227 | PVC insulatas rudentes | plene obsecundantia |
| VDE 0281 | Latin PVC cable vexillum | plene obsecundantia |
| BS 6500 | vexillum flexibile Britannia | plene obsecundantia |
| Ty (IX) DCCLX | Turcorum PVC cable vexillum | plene obsecundantia |
| 60332-1 IEC | Flamma retardatio | Obsequens |
| RoHS | Ancipitia substantiae restrictione | Obsequens |
| SPATIUM | Chemical registration | Obsequens |
| Type Packaging | Application | Longitudo |
|---|---|---|
| Plastic coil | 100 m, 200 m | Parva incepta, retail |
| Lignea orum | 500 m, 1000 m | Magna incepta, industriae |
| Lobortis box | Consuetudinem | OEM, speciality orders |
Modi navicularii: Mare oneraria / Aeris oneraria / terra oneraria
Documenta comprehendit:
Stipare album
Cautionem commercialem
Exercitatione test tradit
Qualis certificatorium
Installation manual
| Exemplar | Cores × mm² | Color | Latin Packing | MOQ |
|---|---|---|---|---|
| LAT-2×1.0 | 2 1.0 | Albus / Niger | C m coil | 10 gyros |
| LAT-2×1.5 | II × 1.5 | Albus / Niger | C m coil | 10 gyros |
| LAT-2×2.5 | II × 2.5 | Albus / Niger | C m coil | 10 gyros |
| LAT-2×4.0 | 2 4.0 | Albus / Niger | C m coil | 10 gyros |
| LAT-3×1.0 | 3 1.0 | Albus / Niger | C m coil | 10 gyros |
| LAT-3×1.5 | III × 1.5 | Albus / Niger | C m coil | 10 gyros |
| LAT-3×2.5 | III × 2.5 | Albus / Niger | C m coil | 10 gyros |
| LAT-3×4.0 | 3 4.0 | Albus / Niger | C m coil | 10 gyros |
Q: Quid interest inter conductores aeris solidi et subductis?
A: Solidum aes (I Classis) unicum est filum - minore impensa, facilior terminatione, et superior vires mechanicae ad certas officinas. Aes destitutum (Class 5/6) magis flexibile est et ad applicationes movendas vel portatiles aptas.
Q: Potestne haec fune foris adhiberi?
A: Non, hic funis ad solum usum umbraticorum destinatur. Ad applicationes velit, UV resistentes considera, vel rudentes tempestatis resistentes quales H05RN-F, H07RN-F, vel XLPE rudentes insulares.
Q: An fune retardat flamma?
A: Ita. Nulla PVC et vagina per IEC 60332-1.
Q: Quid est maximum temperamentum operating?
A: Continuous: 70°C (conductor). Brevis circuitus (≤5s): 160°C.
Q: Tu offeres consuetudine longitudinum?
A: Ita. Consuetudo longitudinum (exempli gratia 50 m, 200 m, 500m) et consuetudo imprimendi in promptu sunt postulante.
Q: Quid est radius minimus flexus?
A: Institutionem certam: 6 diametri altiore. Usus flexibilis: 10 diametro altiore.
Q: Quae signa haec fune parere?
A: IEC 60227, VDE 0281, BS 6500, TS 9760, IEC 60332-1.
Q: Quid est aestimatio voltage?
A: 0.6/1 kv (U₀/U).
Q: Quid crucem-sectiones praesto sunt?
A: 1 mm.
